PRIXTON Snap Pocket DC600 5K 50MP Compact Camera User Manual

1. บทนำ

This manual provides detailed instructions for the safe and effective use of your PRIXTON Snap Pocket DC600 compact camera. The Snap Pocket DC600 is a high-performance compact camera designed to capture moments with exceptional quality, offering 5K video recording and photos up to 50 megapixels. Its features include a 270° rotating screen, a waterproof casing for depths up to 30 meters, and integrated WiFi and USB-C connectivity. This device is suitable for various environments, including aquatic and outdoor adventures.

2. สินค้าหมดview

2.1 คุณสมบัติหลัก

• High-Definition Video and Photography: Records videos up to 5K at 30 frames per second and captures photos up to 50 megapixels, with multiple resolutions available.
• Multi-Angle Design with Touch Screen: Features a 1.3-inch IPS touch screen with 270° rotation for flexible framing, ideal for selfies and creative shots.
• กันน้ำ Casing up to 30 Meters: Protected by a waterproof case, making it suitable for water sports, diving, and extreme activities without compromising image quality.
• การเชื่อมต่ออัจฉริยะ: Includes integrated WiFi for remote control and fast content transfer. Connects via USB-C and allows content management through the SupCam Pro application, compatible with iOS and Android.
• Battery Life and Storage: Equipped with a 1000 mAh battery, providing up to 90 minutes of continuous recording. Supports microSD cards up to 256 GB.

2.2 ส่วนประกอบของกล้อง

3. การตั้งค่า

3.1 การชาร์จแบตเตอรี่

Before first use, fully charge the camera's internal 1000 mAh battery. Connect the included USB-C cable to the camera's USB-C port (refer to Image 3) and the other end to a standard USB power adapter (not included) or a computer's USB port. The charging indicator light will show the charging status.

3.2 การใส่การ์ด MicroSD

The camera requires a microSD card (up to 256 GB, not included) for storing photos and videos. Locate the microSD card slot on the side of the camera (refer to Image 3). Gently insert the microSD card with the contacts facing down until it clicks into place. To remove, press the card in again until it springs out.

3.3 การเปิดเครื่องครั้งแรก

Press and hold the Power button (usually marked with a ⑂ symbol) for a few seconds until the screen illuminates. Follow any on-screen prompts for initial setup, such as language and date/time settings.

3.4 Connecting to the Mobile Application

Download the 'SupCam Pro' application from your device's app store (iOS or Android). Enable WiFi on your camera and connect your smartphone to the camera's WiFi network. Open the SupCam Pro app to control the camera remotely and transfer media files.

4. คู่มือการใช้งาน

4.1 การควบคุมขั้นพื้นฐาน

• ปุ่มเปิด/ปิด: Press and hold to turn on/off. Short press to switch between modes or confirm selections.
• ปุ่มโหมด (M): Short press to cycle through different shooting modes (e.g., video, photo, playback).
• Navigation Buttons (Up/Down): Used to navigate menus or zoom in/out in certain modes.
• ปุ่มชัตเตอร์/บันทึก: Press to start/stop video recording or take a photo.

4.2 การบันทึกวิดีโอ

In video mode, press the Shutter/Record button to begin recording. Press it again to stop. The camera supports resolutions up to 5K at 30fps. Adjust video settings (resolution, frame rate) via the on-screen menu.

4.3 การจับภาพ

In photo mode, press the Shutter/Record button to take a picture. The camera can capture photos up to 50 megapixels. Adjust photo settings (resolution, timer) via the on-screen menu.

4.4 Using the 270° Rotating Screen

The camera's 1.3-inch IPS touch screen can rotate 270 degrees. This allows for flexible viewing angles, making it easy to frame shots from various perspectives, including selfies. Simply adjust the screen to your desired position.

4.5 Waterproof Usage

When using the camera in or near water, ensure it is properly enclosed within its waterproof casing (refer to Image 4). Verify that all seals are clean and securely closed before submersion. The camera is waterproof up to 30 meters with the casing.

5. การบำรุงรักษา

5.1 การทำความสะอาด

• ตัวกล้อง: เช็ดด้วยผ้านุ่มและแห้ง สำหรับคราบฝังแน่น ให้ใช้ผ้านุ่มๆ เช็ดเบาๆamp ผ้าแล้วเช็ดให้แห้งสนิท
• เลนส์: Use a lens cleaning cloth or brush to gently remove dust. Avoid touching the lens with fingers.
• กันน้ำ Casing: After use in saltwater, rinse the casing with fresh water and allow it to air dry. Ensure no sand or debris is trapped in the seals.

5.2 การดูแลแบตเตอรี่

To prolong battery life, avoid exposing the camera to extreme temperatures. Charge the battery regularly, even if not in use, to prevent deep discharge. If storing for extended periods, charge the battery to about 50%.

5.3 พื้นที่จัดเก็บ

Store the camera in a cool, dry place away from direct sunlight and excessive humidity. When transporting, use a protective case to prevent scratches and damage.

6 การแก้ไขปัญหา

• กล้องไม่เปิด: Ensure the battery is charged. If the issue persists, try resetting the camera using the small reset button (refer to Image 3) with a thin pin.
• Cannot record or take photos: Check if a microSD card is inserted and has sufficient free space. Ensure the card is formatted correctly (FAT32 or exFAT).
• ปัญหาการเชื่อมต่อ WiFi: Ensure WiFi is enabled on the camera and your mobile device. Restart both devices and try connecting again. Verify the 'SupCam Pro' app is up to date.
• คุณภาพของภาพ/วิดีโอไม่ดี: Check the lens for smudges or dirt. Ensure settings like resolution and exposure are appropriate for the lighting conditions.
• น้ำรั่วซึมในเคสกันน้ำ: Immediately remove the camera from water. Inspect the waterproof casing for cracks or damage. Ensure the seals are clean and properly seated before next use.

7. ข้อมูลจำเพาะ

8. การรับประกันและการสนับสนุน

8.1 ข้อมูลการรับประกัน

Specific warranty details are not provided in this manual. Please refer to the product packaging or the official PRIXTON webเว็บไซต์สำหรับข้อกำหนดและเงื่อนไขการรับประกัน

8.2 การสนับสนุนลูกค้า

For technical assistance, troubleshooting beyond this manual, or inquiries regarding spare parts, please contact PRIXTON customer support through their official website or the contact information provided with your purchase. Spare parts availability information is currently unavailable.
