arboleaf Mini Massage Gun with Heat - Instruction Manual

การแนะนำ

Thank you for choosing the arboleaf Mini Massage Gun with Heat. This device is designed to provide targeted muscle relief through percussion massage and optional heat therapy. Please read this manual thoroughly before use to ensure safe and effective operation.

ข้อมูลด้านความปลอดภัย

• Use only on skin and muscle, not on bones or joints.
• Avoid use on injured or inflamed areas.
• เก็บให้พ้นจากมือเด็ก
• Do not use while sleeping or bathing.
• ปล่อยให้อุปกรณ์เย็นลงระหว่างการใช้งาน
• เก็บไว้ในที่แห้ง
• อย่าให้อุณหภูมิสูงหรือถูกแสงแดดโดยตรง
• Follow the instructions provided with the device.

สินค้าเกินview

The arboleaf Mini Massage Gun is a compact, handheld percussion massager featuring a heated aluminum head and multiple silicone attachments for versatile use. It is designed for muscle relaxation and recovery.

Figure 1: arboleaf Mini Massage Gun with included attachments and carrying case.

ส่วนประกอบ:

• Massage Gun Unit: The main device housing the motor and battery.
• Heated Aluminum Head: One specialized head designed for efficient heat transfer to loosen muscles.
• Soft Silicone Heads (3 types):
  • Ball Head: For large muscle groups.
  • U-Shaped Head: For spine and neck areas.
  • Bullet Head: For deep tissue, joints, and trigger points.
• กระเป๋าใส่อุปกรณ์: A compact case for storage and travel.
• สายชาร์จ USB-C: สำหรับชาร์จแบตเตอรี่อุปกรณ์

Figure 2: The four specialized massage heads: Heated Head, Ball Head, U-Shaped Head, and Bullet Head.

การตั้งค่า

1. การชาร์จอุปกรณ์

Before first use, fully charge the massage gun. Connect the provided USB-C charging cable to the charging port located at the bottom of the handle and to a compatible USB power adapter (not included). The battery indicator lights will illuminate to show charging progress. A full charge provides up to 8 hours of use.

Figure 3: USB-C charging port and battery indicator lights on the arboleaf Mini Massage Gun.

2. การติดตั้งหัวนวด

To attach a massage head, align the head with the opening on the device and push firmly until it clicks into place. To remove, pull the head straight out. Ensure the device is powered off before changing attachments.

คำแนะนำการใช้งาน

1. เปิด/ปิดเครื่อง

• Press and hold the power button (located at the bottom of the handle) for 2 seconds to turn the device ON. It will start at Speed Level 1.
• To turn OFF, press and hold the power button for 2 seconds.

2. การตั้งค่าความเร็ว

The device features 5 speed settings (1700 to 3200 RPM) for customized relief. After powering on, short press the power button to cycle through the speed levels:

• Level 1 (1700 RPM): Warm-up & Relaxation
• Level 2 (2200 RPM): Release Daily Tension
• Level 3 (2700 RPM): Reduce Muscle Soreness
• Level 4 (3200 RPM): Deep Tissue Relief
• Level 5 (Adaptive Pressure Control): Automatically adjusts intensity based on applied pressure.

Figure 4: Visual representation of the 5 speed settings and their corresponding uses.

3. Heat Function Activation

The heated aluminum head provides soothing warmth. To activate the heat function, ensure the heated head is attached. The heat function is integrated into the head itself and can be activated via its own controls (refer to specific instructions for the heated head if separate). The soothing warmth quickly loosens tight muscles and eases deep tension.

Figure 5: The heated aluminum head in operation, showing its orange glow indicating heat.

4. Application Techniques

Apply the massager gently to the target muscle area. Use circular or up-and-down motions. Avoid direct contact with bones, joints, and injured or inflamed areas. The device is suitable for use on the neck, shoulders, back, arms, and legs.

5. ระบบปิดเครื่องอัตโนมัติ

For safety and to prevent overuse, the device features a 15-minute automatic pause function. It will automatically turn off after 15 minutes of continuous operation.

การซ่อมบำรุง

1. การทำความสะอาด

Wipe the device and attachments with a slightly damp ผ้า. อย่าใช้น้ำยาทำความสะอาดที่มีฤทธิ์กัดกร่อนหรือจุ่มอุปกรณ์ลงในน้ำ

2. การจัดเก็บ

Store the massage gun and its accessories in the provided carrying case in a cool, dry place away from direct sunlight and extreme temperatures.

การแก้ไขปัญหา

If the device experiences unexpected behavior, such as intermittent shut-off despite showing a full charge, ensure the battery is indeed fully charged. If issues persist, contact customer support.

ข้อมูลจำเพาะ

วิดีโอผลิตภัณฑ์อย่างเป็นทางการ

การรับประกันและการสนับสนุน

For warranty information or product support, please refer to the contact details provided in your product packaging or visit the official arboleaf webเว็บไซต์.
