คู่มือการใช้งานเก้าอี้โยกปรับเอนสำหรับเด็กอ่อน FLEXISPOT XRC6

การแนะนำ

Thank you for choosing the FLEXISPOT XRC6 Nursery Swivel Rocker Recliner. This manual provides essential information for the safe and efficient assembly, operation, and maintenance of your recliner. Please read all instructions carefully before use and retain this manual for future reference.

Image: The FLEXISPOT XRC6 recliner, highlighting its massage function.

ข้อมูลด้านความปลอดภัยที่สำคัญ

To reduce the risk of injury, please observe the following safety precautions:

• ตรวจสอบให้แน่ใจว่าชิ้นส่วนทั้งหมดถูกยึดอย่างแน่นหนาก่อนใช้งาน
• Keep children and pets away from the recliner's moving parts.
• ห้ามยืนบนเก้าอี้เอนหลัง หรือใช้เป็นบันไดปีนขึ้นลง
• Avoid placing heavy objects on the footrest when extended.
• Unplug the power cord before cleaning or if the recliner will be unused for an extended period.
• รับน้ำหนักสูงสุด : 300 lbs.

คู่มือการติดตั้ง

The FLEXISPOT XRC6 recliner is designed for easy assembly. It ships in two compact boxes. Follow these steps for proper installation:

1. แกะส่วนประกอบ: Carefully remove all parts from the packaging. Verify that you have the seat, backrest, two armrests, adjustment lever, remote control, adapter, screws, flat washers, nuts, wrench, and hex key.
2. ติดที่วางแขน: Align the hook-loop brackets on the armrests with the corresponding slots on the seat base. Gently push down until each armrest locks into position.
3. Insert Adjustment Lever: With the chair on its side, insert the angle adjustment lever into its designated slot on the side of the seat base.
4. สกรูยึด: Locate the screw installation area. Insert the provided screws, ensuring correct orientation.
5. Extend Footrest: To access the remaining installation area, extend the footrest using the lever.
6. Fasten with Washers and Nuts: Secure the components using the washers and nuts provided. Ensure all connections are tight.
7. ติดตั้งพนักพิง: Align the backrest with the seat base. Push down firmly until you hear a "click," indicating proper installation.
8. เชื่อมต่อสายไฟ: Locate the power wires for the massage and heat functions. Connect them securely.
9. ติดแผงด้านหลัง: Attach the velcro on the backrest rear panel to secure it in place, covering the wires.

Image: Product dimensions and shipping information.

คำแนะนำการใช้งาน

Reclining and Rocking Functions

• เอนนอน: Pull the manual lever located on the side of the recliner to extend the footrest and recline the backrest. Push back with your body weight to achieve your desired recline angle.
• กลับสู่ท่าตั้งตรง: To return to the upright position, gently push the footrest down with your legs and lean forward. The backrest will follow.
• หมุน: The recliner features a 360° swivel base, allowing you to rotate freely.
• การโยก: The chair provides a gentle 30° back-and-forth rocking motion for comfort.

Image: Manual swivel, rock, and recline adjustment with pull handle.

Image: Full recline position for relaxation.

Massage and Heat Functions

The recliner includes a remote control for activating and adjusting the massage and heat features.

• เปิด/ปิดเครื่อง: Use the power button on the remote to turn the massage and heat functions on or off.
• โหมดการนวด: Select from multiple massage modes (e.g., pulse, press, wave, auto) using the 'Mode' button.
• ระดับความเข้ม: Adjust the massage intensity (high, medium, low) with the 'Intensity' buttons.
• การนวดแบบกำหนดเป้าหมาย: Use the 'Part' button to select specific areas for massage, such as the back or lumbar region.
• ฟังก์ชั่นความร้อน: Press the 'Heat' button to activate the lumbar heating function. The indicator light will turn red when active.
• ตัวจับเวลา: Set a timer for your massage session using the 'Time' button.

Image: Remote control for massage and heat functions.

การดูแลรักษา

• การดูแลรักษาผ้า: The OEKO-TEX certified chenille fabric is spill-resistant. For spills and everyday messes, wipe clean with a damp ผ้า. หลีกเลี่ยงสารเคมีที่รุนแรง
• การทำความสะอาดทั่วไป: Regularly vacuum the recliner to remove dust and debris.
• ชิ้นส่วนที่เคลื่อนไหว: Periodically check all screws and connections to ensure they are tight. Lubricate moving metal parts if necessary, following manufacturer guidelines.
• สายไฟ: ตรวจสอบสายไฟว่ามีรอยชำรุดหรือไม่ หากพบรอยชำรุด ให้หยุดใช้งานและติดต่อฝ่ายบริการลูกค้า

Image: Details of the recliner's chenille fabric and comfort features.

การแก้ไขปัญหา

If you encounter any issues with your recliner, please refer to the following common solutions:

• Recliner Not Reclining:
  • Ensure the manual lever is fully pulled.
  • Check for any obstructions preventing the footrest or backrest from moving.
• Massage/Heat Not Working:
  • Verify that the power adapter is securely plugged into both the recliner and a working wall outlet.
  • ตรวจสอบว่าได้กดปุ่มเปิด/ปิดบนรีโมทคอนโทรลแล้วหรือไม่
  • Ensure all internal wires are properly connected (refer to Setup Guide).
• Unstable or Wobbly:
  • Confirm that all assembly screws and nuts are tightened.
  • Ensure the recliner is placed on a flat, even surface.

If the issue persists, please contact FLEXISPOT customer support.

ข้อมูลจำเพาะ

การรับประกันและการสนับสนุน

FLEXISPOT products are manufactured with quality and durability in mind. For specific warranty details, please refer to the warranty card included with your product or visit the official FLEXISPOT webเว็บไซต์.

For customer support, technical assistance, or to inquire about replacement parts, please contact FLEXISPOT directly or visit their official store:
