Force USA Home Gym Pro 2

1. บทนำ

ยินดีต้อนรับสู่คู่มือผู้ใช้สำหรับเครื่องใหม่ของคุณ Force USA Home Gym Pro 2. This comprehensive guide provides essential information for the safe and effective use of your fitness equipment. Please read this manual thoroughly before operating the machine to ensure proper setup, operation, and maintenance, maximizing your workout experience and the longevity of your gym.

2. คำแนะนำด้านความปลอดภัย

Your safety is paramount. Adhere to the following guidelines to prevent injury and ensure safe operation:

• ปรึกษาแพทย์: Before starting any exercise program, consult with a healthcare professional to ensure you are physically fit for the exercises.
• อ่านคำแนะนำทั้งหมด: Familiarize yourself with all assembly (if applicable) and operating instructions before using the equipment.
• การตั้งค่าที่เหมาะสม: Ensure the gym is placed on a stable, level surface. Do not use on uneven ground.
• ตรวจสอบก่อนใช้งาน: Before each workout, check all bolts, nuts, and connections to ensure they are securely fastened. Do not use the equipment if any components are loose or damaged.
• รูปแบบที่ถูกต้อง: Always maintain correct posture and form during exercises. Incorrect form can lead to injury. If you experience pain, stop immediately.
• ขีดจำกัดน้ำหนัก: Do not exceed the maximum user weight capacity of 158kg (348 lbs).
• เด็กและสัตว์เลี้ยง: โปรดกันเด็กและสัตว์เลี้ยงให้ออกห่างจากอุปกรณ์ขณะใช้งาน อุปกรณ์นี้ไม่ใช่ของเล่น
• เคลียร์สต๊อก : Ensure adequate clear space around the equipment for safe operation and movement.
• การซ่อมบำรุง: Perform regular maintenance as outlined in this manual to keep the equipment in optimal condition.

3. สินค้าหมดview

The Force USA Home Gym Pro 2 is a versatile, high-performance trainer designed for a complete full-body workout. It features a 90kg pin-loaded weight stack and a heavy-duty high-tensile steel frame, ensuring durability and stability for various fitness levels.

รูปที่ 3.1: โดยรวม view of the Force USA Home Gym Pro 2. This image displays the complete multi-station gym, highlighting its compact yet robust design suitable for home or professional use.

คุณสมบัติหลัก:

• 90kg Pin-Loaded Weight Stack: Provides resistance from 4.5kg to 90kg (10lbs-198lbs) with easy pin selection.
• การออกแบบแบบมัลติฟังก์ชัน: Supports exercises like Chest Press, Chest Fly, Lat Pulldown, Seated Row, Leg Press, Leg Extension, Shoulder Press, and more.
• โครงสร้างทนทาน: Heavy-duty high-tensile steel frame with commercial-grade fixtures, laser-cut, and robotically welded for longevity.
• ระบบสายเคเบิลแบบเรียบ: Fully adjustable with 10 unique settings, 2,000lbs aircraft-rated cables, and sealed bearing pulleys for fluid motion.
• ความสะดวกสบายและการรองรับ: Tear-resistant seat with deluxe upholstered cushioning and thick padded backrest for proper form.

Figure 3.2: Labeled exercise stations and components. This image points out key areas such as the Lat Pulldown, Abs/Core station, Cable Fly, Chest Press/Seated Row, Leg Press, and Leg Lift, illustrating the machine's versatility.

4. การตั้งค่า

The Force USA Home Gym Pro 2 is designed for professional assembly by the seller to ensure optimal performance and safety. This section outlines important considerations for placement and initial checks.

• การประกอบแบบมืออาชีพ: Your Force USA Home Gym Pro 2 has been assembled by qualified personnel. Do not attempt to disassemble or reassemble the main structural components unless instructed by a certified technician.
• การจัดวาง: Position the gym on a flat, stable, and non-slip surface. Ensure there is sufficient clearance around the machine for safe operation and movement, as well as for accessing all exercise stations.
• การตรวจสอบเบื้องต้น: After placement, perform a visual inspection to ensure all parts are intact and no shipping damage occurred. Verify that all cables are properly routed and pulleys move freely.
• การตรวจสอบเสถียรภาพ: Gently rock the machine to confirm it is stable and does not wobble. Adjust if necessary to ensure a firm base.

Figure 4.1: Product dimensions for placement planning. The image shows the gym's length (198cm), width (179cm), and height (205cm), crucial for determining suitable installation space.

5. คู่มือการใช้งาน

The Force USA Home Gym Pro 2 offers a wide range of exercises. Always ensure proper form and adjust settings before beginning your workout.

5.1. Adjusting Weight Resistance

The weight stack allows for quick and easy resistance changes:

• Locate the selector pin on the weight stack.
• Insert the pin into the desired weight plate. Ensure the pin is fully inserted through the stack.
• Resistance levels range from 4.5kg (10lbs) to 90kg (198lbs).

Figure 5.1: Detail of the weight stack adjustment pin. This image shows the red selector pin used to easily change the resistance level by inserting it into the desired weight plate.

5.2. Cable System Adjustments

The smooth, fully adjustable cable system features 10 unique settings:

• Identify the cable arm adjustment points.
• Adjust the cable arms to one of the 10 available angle settings to target different muscle groups or accommodate various exercises.
• Use the carabiner attachment for quick accessory swaps (e.g., Lat Bar, Ab Strap, Single Handles).

5.3. Seat Adjustments

The Lat Pulldown seat offers vertical adjustment for user comfort and proper exercise mechanics:

• Locate the seat adjustment mechanism.
• Adjust the seat height to ensure your knees are at a comfortable angle and your feet are flat on the floor or footrests during exercises like Lat Pulldowns.
• The Leg Press seat height is fixed at 46cm for optimal leg press mechanics.

Figure 5.2: Leg press seat height detail. This image illustrates the fixed height of the leg press seat at 46cm, designed for effective lower body training.

5.4. Included Attachments and Exercises

Your Force USA Home Gym Pro 2 includes the following attachments:

• 1 x Lat Bar
• 1 x Ab Strap
• 2 x Single Handles

Utilize these attachments to perform a variety of exercises:

• Chest Press / Seated Row: Adjust the chest press arm for either pressing movements or seated rows.
• Lat Pulldown: Use the Lat Bar with the upper pulley for back exercises.
• เครื่องเพรสขา: Utilize the dedicated leg press station for targeted lower body training.
• การต่อขา / ขา Curl: Attach the appropriate accessory to the leg developer for these exercises.
• Cable Fly / Shoulder Press: Use the adjustable cable arms and single handles for various chest and shoulder exercises.
• Abdominal Crunches: Attach the Ab Strap to the upper pulley for core workouts.

Figure 5.3: Detail of the Lat Bar. This image provides a close-up view of the Lat Bar, an essential attachment for back and arm exercises.

6. การบำรุงรักษา

Regular maintenance is crucial for the longevity and safe operation of your Force USA Home Gym Pro 2. Follow these steps to keep your equipment in optimal condition:

• การทำความสะอาด: Wipe down the frame, seats, and handles with a damp cloth after each use to remove sweat and dirt. Use a mild, non-abrasive cleaner if necessary. Avoid harsh chemicals that could damage the finish or upholstery.
• ตรวจสอบสายเคเบิลและรอก: Periodically check the aircraft-rated cables for any signs of fraying, wear, or damage. Ensure all sealed bearing pulleys rotate smoothly and are free of debris. Replace any damaged cables immediately.
• ตรวจสอบตัวยึด: Every 1-3 months, inspect all nuts, bolts, and screws. Tighten any loose fasteners to prevent wobbling and ensure structural integrity. Do not overtighten.
• การหล่อลื่น: While the sealed bearing pulleys are designed for smooth operation, a light application of silicone-based lubricant on guide rods (if accessible and recommended by manufacturer) can help maintain smooth movement of the weight stack. Avoid oil-based lubricants on cables.
• การดูแลเบาะ: Keep the upholstered seats and backrests clean and dry. Avoid sharp objects that could puncture or tear the material.
• พื้นที่จัดเก็บ: If storing the gym for an extended period, ensure it is clean and dry. Store in a climate-controlled environment to prevent rust or material degradation.

7 การแก้ไขปัญหา

This section addresses common issues you might encounter with your Force USA Home Gym Pro 2. For problems not listed here, or if solutions do not resolve the issue, please contact customer support.

8. ข้อมูลจำเพาะ

Detailed technical specifications for the Force USA Home Gym Pro 2:

• ขนาดสินค้า (กว้าง x ยาว x สูง) : 198 ซม. x 179 ซม. x 205 ซม. (78 นิ้ว x 70.5 นิ้ว x 80.7 นิ้ว)
• น้ำหนักผลิตภัณฑ์: 290.5 กก. (640.4 ปอนด์)
• น้ำหนักผู้ใช้สูงสุด: 158 กก. (348 ปอนด์)
• กองน้ำหนัก: 1 x 90 kg (198 lbs) pin-loaded
• Pulley Ratio: 2:1 Cable Ratio
• Cable Arm Adjustability: 10 angle adjustments
• Lat Pulldown Seat Adjustment: การปรับแนวตั้ง
• Lat Pulldown Seat Height: 56 ซม. (22 นิ้ว)
• Leg Press Seat Height: 46 ซม. (18.1 นิ้ว)
• ความหนาของเบาะ: 5 ซม. (2 นิ้ว)
• วัสดุกรอบ: Heavy-duty high-tensile steel, laser-cut, robotically welded
• สาย: 2,000 lbs aircraft-rated cables
• รอก: Sealed bearing pulleys
• สี: สีดำ

9. การรับประกันและการสนับสนุน

For warranty information regarding your Force USA Home Gym Pro 2, please refer to the documentation provided at the time of purchase or contact the seller directly. Warranty terms and conditions may vary.

If you require technical assistance, have questions about operation, or need to report an issue, please contact the seller, GYMSPORTZ PTE LTD, through your purchase platform or their official contact channels. Please have your product model number (Force USA Home Gym Pro 2) and purchase details ready when contacting support.
