คู่มือการใช้งาน CME H4MIDI WC

1. บทนำและเรื่องอื่นๆview

The CME H4MIDI WC is a versatile and advanced USB Host MIDI Interface designed for musicians, producers, and guitarists. It provides seamless connectivity between various MIDI devices, offering robust routing, filtering, and mapping capabilities without requiring a computer for standalone operation. Its compact design and flexible power options make it ideal for both studio and live performance environments.

This manual provides detailed instructions for setting up, operating, and maintaining your H4MIDI WC, ensuring you can fully utilize its extensive features.

2. คุณสมบัติหลัก

• Standalone USB Host: Connect class-compliant USB MIDI instruments directly to your MIDI hardware without a computer. Supports up to 8 USB MIDI device ports via a standard USB hub.
• Multi-Mode Flexibility: Connect to your computer via USB-C for 4 inputs and 4 outputs of virtual MIDI ports. Compatible with MacOS, Windows, iOS, Android, Linux, and ChromeOS.
• Standalone Dual Power: Flexible power options with 5V USB or 9V DC, suitable for studio or stagอีใช้
• Real-Time MIDI Control: Configure MIDI thru, split, merge, mapper, and filter options using HxMIDI Tools (Windows, macOS, iOS, Android) for advanced MIDI routing and processing.
• Optional WIDI Bluetooth MIDI: Expand capabilities with the optional WIDI Core module for wireless MIDI connectivity.

3. การตั้งค่า

To set up your CME H4MIDI WC, follow these steps:

1. การเชื่อมต่อไฟฟ้า: Connect the H4MIDI WC to a power source using either a 5V USB-C cable or a standard 9V DC power supply.
2. การเชื่อมต่อ MIDI: Connect your 5-pin DIN MIDI devices to the MIDI IN and MIDI OUT ports on the H4MIDI WC.
3. USB MIDI Connections: Connect your class-compliant USB MIDI instruments to the USB-A host port. For multiple USB devices, use a standard USB hub connected to the USB-A port.
4. Computer Connection (Optional): For computer-based control and virtual MIDI ports, connect the H4MIDI WC to your computer via the USB-C port.
5. WIDI Core Installation (Optional): If using WIDI Bluetooth MIDI, insert the WIDI Core module into its designated slot.

4. โหมดการทำงาน

The H4MIDI WC supports several operating modes to accommodate diverse MIDI setups:

4.1. Simple Mode: USB MIDI to 5-pin DIN (Standalone)

In this mode, the H4MIDI WC acts as a bridge, allowing USB MIDI devices to communicate directly with 5-pin DIN MIDI hardware without the need for a computer. Simply connect your USB MIDI controller to the USB-A host port and your 5-pin DIN MIDI device to the MIDI IN/OUT ports.

4.2. Expand Mode: Multiple USB Host Ports

Utilize a standard USB hub connected to the H4MIDI WC's USB-A host port to expand your USB MIDI connectivity up to 8-in-8-out host ports. This allows for simultaneous connection and control of multiple USB MIDI devices alongside your 5-pin DIN MIDI gear.

4.3. Advanced Mode: Virtual MIDI Ports via USB-C

When connected to a computer via USB-C, the H4MIDI WC provides 4 inputs and 4 outputs of virtual MIDI ports. This enables seamless integration with your Digital Audio Workstation (DAW) and other music software, allowing for complex MIDI routing and control within your computer environment.

4.4. Innovate Mode: WIDI Bluetooth MIDI (Optional)

For wireless MIDI connectivity, the H4MIDI WC supports the optional WIDI Core module. This provides ultra-low latency Bluetooth MIDI, allowing you to connect compatible wireless MIDI devices and reduce cable clutter in your setup.

4.5. Customize Mode: HxMIDI Tools Software

The HxMIDI Tools software (available for Windows, macOS, iOS, and Android) provides comprehensive control over the H4MIDI WC's MIDI routing, filtering, and mapping capabilities. This allows for precise customization of MIDI messages to suit your specific workflow and device requirements.

4.6. วิดีโอสาธิตผลิตภัณฑ์

Watch this official video from CME Pro to see the H4MIDI WC in action and understand its various functionalities and applications.

5. การเชื่อมต่อ

The H4MIDI WC offers comprehensive connectivity options:

• 5-pin DIN MIDI: Two input and two output ports for traditional MIDI hardware.
• USB-A Host: One port for connecting class-compliant USB MIDI devices. Expandable up to 8-in-8-out via a USB hub.
• USB-C Client: One port for connecting to computers, providing 4-in-4-out virtual MIDI ports.
• WIDI Bluetooth MIDI: Optional wireless connectivity via the WIDI Core module, offering 1-in-1-out BLE MIDI and 1-to-4/4-to-1 group connectivity.

6. อำนาจ

The CME H4MIDI WC can be powered in two ways:

• 5V USB Power: Connect a standard USB-C cable to a 5V USB power adapter or a computer's USB-C port.
• 9V DC Power: Use a standard 9V DC power supply (center negative, 1A minimum) for standalone operation, particularly useful for integration with guitar pedalboards.

7. การบำรุงรักษา

To ensure the longevity and optimal performance of your H4MIDI WC, follow these general maintenance guidelines:

• รักษาความสะอาดของอุปกรณ์ด้วยการเช็ดด้วยผ้านุ่มและแห้ง หลีกเลี่ยงการใช้น้ำยาทำความสะอาดหรือสารละลายที่มีฤทธิ์กัดกร่อน
• Protect the device from extreme temperatures, humidity, and direct sunlight.
• หลีกเลี่ยงการทำอุปกรณ์หล่นหรือกระแทกอย่างรุนแรง
• Ensure all cables are connected securely but without excessive force to prevent damage to the ports.

8 การแก้ไขปัญหา

If you encounter issues with your H4MIDI WC, consider the following troubleshooting steps:

• ไม่มีไฟฟ้า: Verify that the power cable is securely connected and the power source (USB adapter or 9V DC supply) is functioning correctly.
• No MIDI Signal: Check all MIDI and USB cable connections. Ensure that your connected devices are powered on and sending/receiving MIDI data.
• Incorrect MIDI Routing/Behavior: Connect the H4MIDI WC to a computer and use the HxMIDI Tools software to review and adjust your MIDI routing, filtering, and mapping settings. Ensure the correct presets are loaded.
• อุปกรณ์ USB ไม่ได้รับการตรวจพบ: Confirm that your USB MIDI device is class-compliant. If using a USB hub, ensure it is powered and functioning correctly.
• WIDI Bluetooth Issues: Ensure the optional WIDI Core module is correctly installed. Refer to the WIDI Core manual for specific Bluetooth pairing and troubleshooting steps.
• อัพเดตเฟิร์มแวร์: Check the CME Pro website for the latest firmware updates for your H4MIDI WC, as updates can resolve known issues and improve performance.

For persistent issues, please refer to the support section on the CME Pro webเว็บไซต์.

9. ข้อมูลจำเพาะ

10. การรับประกันและการสนับสนุน

การรับประกัน: The CME H4MIDI WC comes with a 1-year warranty from the date of purchase. Please retain your proof of purchase for warranty claims.

สนับสนุน: For technical assistance, product inquiries, or warranty support, please visit the official CME Pro support page:

cme-pro.com/support

CME offers reliable, people-centric support within 24 hours and provides lifetime updates via HxMIDI Tools.
