Anweller Fingerprint Electronic Door Lock L111-70mm User Manual

1. บทนำ

Thank you for choosing the Anweller Fingerprint Electronic Door Lock L111-70mm. This manual provides detailed instructions for the installation, operation, and maintenance of your new smart lock. Please read this manual carefully before installation and use to ensure proper function and security. Keep this manual for future reference.

2. สินค้าหมดview

The Anweller L111-70mm is an advanced electronic door lock cylinder designed for enhanced security and convenience. It offers multiple unlocking methods and smart features for modern access control.

Image 2.1: Anweller L111-70mm Fingerprint Electronic Door Lock components including the cylinder, keys, and IC cards.

คุณสมบัติหลัก:

• Five Unlock Modes: Fingerprint, Password, RFID Card, Tuya App, and Mechanical Keys.
• ความปลอดภัยสูง: Constructed from heavy alloy material for durability and enhanced security.
• ติดตั้งง่าย: Designed for quick replacement of existing locks without additional drilling.
• อายุการใช้งานแบตเตอรี่ยาวนาน: Low power consumption ensures extended battery operation with low battery warnings.
• การควบคุมแอพอัจฉริยะ: Manage users, generate temporary passwords, and monitor lock status via the Tuya app.

Image 2.2: Visual representation of the five available unlock methods: Passcode, Tuya APP, Fingerprint, IC Card, and Mechanical Key.

3. การตั้งค่าและการติดตั้ง

The Anweller L111-70mm lock cylinder is designed for straightforward installation, typically replacing an existing lock without the need for drilling.

3.1 ความเข้ากันได้กับประตู

• 70mm Lock Cylinder: เหมาะสำหรับประตูที่มีความหนาตั้งแต่ 35 มม. ถึง 70 มม.
• Ensure the distance between the cylinder lock hole and the door frame is at least 50mm.

3.2 ขั้นตอนการติดตั้ง (คู่มือทั่วไป)

1. Remove your existing lock cylinder.
2. Insert the Anweller L111-70mm cylinder into the door.
3. Secure the cylinder with the provided screw set.
4. Install 4 AAA batteries (not included) into the battery compartment.
5. Follow the instructions in the included user manual for initial setup and programming.

Image 3.1: Guide for measuring door thickness and ensuring compatibility for installation. The 70mm cylinder is suitable for doors 35-70mm thick.

4. คู่มือการใช้งาน

The Anweller L111-70mm offers multiple convenient ways to unlock your door.

4.1 ปลดล็อคด้วยลายนิ้วมือ

• The lock can store up to 100 unique fingerprints.
• To unlock, place your registered finger on the sensor. The lock will disengage upon successful recognition.
• The fingerprint sensor features enhanced sensitivity and recognition speed for reliable access.

Image 4.1: Illustration of the larger fingerprint recognition area and improved sensitivity for quick and accurate unlocking.

4.2 การปลดล็อกด้วยรหัสผ่าน

• The lock supports up to 100 passwords.
• Enter your registered password on the keypad, then press '#' to confirm and unlock.
• รหัสผ่านชั่วคราว: The Tuya app allows you to generate various types of temporary passwords:
  • รหัสแบบใช้ครั้งเดียว: For single use.
  • รหัสจำกัดเวลา: Valid for a specific duration.
  • Dynamic passwords: For flexible access.
  • User-defined codes: Customizable codes.

ภาพที่ 4.2: จบแล้วview of multifunctional password options available through the lock system.

ภาพที่ 4.3: อดีตample of generating and sharing temporary passwords remotely via the mobile application.

4.3 RFID Card Unlock

• Two RFID cards are included with the lock.
• To unlock, present a registered RFID card to the designated sensor area on the lock.

4.4 การควบคุมแอป Tuya

• Download the Tuya app from your device's app store.
• Pair the lock with the app following the in-app instructions.
• The app allows for remote unlocking, user management, generation of temporary passwords, checking battery status, and viewing unlock logs.

Image 4.4: Features of the intelligent app control, including temporary password settings, user management, battery status, and access logs.

4.5 การปลดล็อคด้วยกุญแจแบบกลไก

• Two mechanical keys are provided for emergency access.
• Insert the key into the keyhole and turn to unlock the door manually.

4.6 การจัดการแบตเตอรี่

• The lock operates on 4 AAA batteries (not included).
• It features low power consumption, providing approximately one year of battery life.
• A low battery warning will alert you when batteries need replacement.
• In case of complete battery depletion, the lock can be temporarily powered via a USB power bank for emergency access, or unlocked using the mechanical keys.

Image 4.5: Information on battery longevity and emergency power options for the lock.

5. การบำรุงรักษา

To ensure the longevity and optimal performance of your Anweller L111-70mm lock, follow these maintenance guidelines:

• การทำความสะอาด: เช็ดพื้นผิวของตัวล็อคด้วยผ้าแห้งเนื้อนุ่ม หลีกเลี่ยงการใช้สารทำความสะอาดที่มีฤทธิ์กัดกร่อน ตัวทำละลาย หรือสารเคมีรุนแรง เพราะอาจทำให้พื้นผิวและชิ้นส่วนอิเล็กทรอนิกส์เสียหายได้
• การเปลี่ยนแบตเตอรี่: Replace all 4 AAA batteries when the low battery warning is activated. Use high-quality alkaline batteries for best performance.
• เซ็นเซอร์ลายนิ้วมือ: Keep the fingerprint sensor clean and dry for accurate recognition.
• ปุ่มกด: Ensure the keypad is free from dirt or debris that could obstruct button presses.
• กุญแจเครื่องกล: Store the mechanical keys in a safe, accessible location outside the property for emergency use.

6 การแก้ไขปัญหา

If you encounter issues with your Anweller L111-70mm lock, refer to the following common problems and solutions:

• ล็อคไม่ตอบสนอง: Check battery level. If batteries are depleted, use a USB power bank for emergency power or the mechanical key.
• ไม่รู้จักลายนิ้วมือ: ตรวจสอบให้แน่ใจว่านิ้วของคุณสะอาดและแห้ง หากปัญหายังคงอยู่ ให้ลงทะเบียนลายนิ้วมืออีกครั้ง
• รหัสผ่านไม่ทำงาน: Verify the correct password is being entered. Check for any debris on the keypad.
• ปัญหาการเชื่อมต่อแอป: Ensure Bluetooth is enabled on your phone and the lock is within range. Restart the app and try reconnecting.
• Lock is making unusual noises: ติดต่อฝ่ายสนับสนุนลูกค้าเพื่อขอความช่วยเหลือ

For further assistance, consult the full user manual included with your product or contact Anweller customer support.

7. ข้อมูลจำเพาะ

8. การรับประกันและการสนับสนุน

Specific warranty information is typically provided with the product packaging or can be obtained directly from the manufacturer. Please refer to the documentation included in your product box for warranty details.

For technical support, troubleshooting assistance, or any questions regarding your Anweller Fingerprint Electronic Door Lock, please contact Anweller customer service through the contact information provided in your product documentation or on the official Anweller webเว็บไซต์.
