การแนะนำ
The Armytek Wizard C2 Pro Max is a versatile 3-in-1 multi-flashlight designed for various uses including as a headlamp, an everyday carry light, and a bicycle light. It features powerful electronics providing an impressive light output of up to 4000 lumens and a record 64 days in Firefly mode. This manual provides detailed instructions for setting up, operating, and maintaining your device to ensure optimal performance and longevity.
มีอะไรอยู่ในกล่อง
Upon unboxing your Armytek Wizard C2 Pro Max, please ensure all components are present:
- Armytek Wizard C2 Pro Max Headlamp
- เฮดลamp สายรัด
- คลิปหนีบเข็มขัด
- ที่ยึดจักรยาน
- แบตเตอรี่ลิเธียมไอออน 1 ก้อน (รวมอยู่ด้วย)
- Eco Sensa Magnetic USB Charging Cable

Image: The Armytek Wizard C2 Pro Max headlamp shown with its included accessories: the headlamp strap, magnetic USB charging cable, 21700 5000mAh Li-ion battery, and a metal belt clip. The product box is also visible.
การตั้งค่า
การติดตั้งและการชาร์จแบตเตอรี่
- ค่าใช้จ่ายเริ่มต้น: Before first use, fully charge the included Lithium Ion battery. Connect the magnetic USB charging cable to the tailcap of the headlamp. For proper charging, ensure you unscrew the tailcap by approximately 1/4 turn first. The indicator light on the charger will show charging status.
- การใส่แบตเตอรี่: Ensure the battery is inserted with the positive (+) end facing towards the head of the flashlight.

Image: The Armytek Wizard C2 Pro Max headlamp with its magnetic charging cable attached to the tailcap, illustrating the charging connection.
การติดตั้งอุปกรณ์เสริม
- เฮดลamp สายคล้อง: เลื่อนศีรษะamp into the silicone mount on the headlamp strap. The flashlight is easily installed, removed, and 180 degrees rotatable in the mount. A quick-release rubber ring provides additional fixation.
- คลิปหนีบเข็มขัด: Attach the robust steel clip to the body of the flashlight for easy everyday carry.
- ที่ยึดจักรยาน: Secure the bike mount to your bicycle handlebars and then attach the headlamp to the mount.

Image: The Armytek Wizard C2 Pro Max headlamp securely mounted on a bicycle handlebar, demonstrating its use as a bike light.
คำแนะนำการใช้งาน
The Armytek Wizard C2 Pro Max offers multiple operating modes and brightness levels for various situations.
การทำงานพื้นฐาน
- เปิด/ปิดเครื่อง: Press the side button once to turn the light on or off.
- โหมดการปั่นจักรยาน: With the light on, press and hold the side button to cycle through the main brightness modes (Low, Medium, High). Release the button to select the desired mode.
- Last Used Mode Memory: The light remembers the last used mode when switched off and will return to it upon turning back on.
Advanced Operation (Advanced Mode)
The Wizard C2 Pro Max features an advanced mode with 12 different settings, including 3 strobe modes and 9 different brightness settings. To access advanced features:
- Direct to Main Modes: Double-click the side button to go directly to the main modes.
- Direct to Turbo Modes: Triple-click the side button to access the Turbo modes (Turbo 1, Turbo 2, Turbo 3).
- Direct to Strobe Modes: Four clicks will take you directly to the Strobe modes. There are three different strobe frequencies available.
Brightness Levels and Runtimes
เฮดลamp offers various brightness levels, with specific runtimes:
- โหมดเทอร์โบ: Up to 4000 lumens. Note that the light will step down after approximately 30 seconds in Turbo mode to prevent overheating. The second highest level is about 2750 lumens, and the highest is 2500 lumens.
- เอาท์พุตคงที่: The maximum constant lumen level you can maintain over a long period without step-down is 650 lumens.
- โหมดหิ่งห้อย: The lowest setting, offering extended runtime of up to 64 days.

Image: The powerful beam of the Armytek Wizard C2 Pro Max illuminating a smoky outdoor environment, demonstrating its wide floodlight pattern.
การซ่อมบำรุง
- การทำความสะอาด: ทำความสะอาดเลนส์และตัวไฟฉายอย่างสม่ำเสมอamp ด้วยความนุ่มนวลamp cloth. Avoid abrasive materials that could scratch the tempered glass with anti-reflective coating.
- การดูแลแบตเตอรี่ Use only the recommended Lithium Ion batteries. Store the battery in a cool, dry place when not in use. Recharge the battery regularly to maintain its lifespan.
- การป้องกันน้ำและฝุ่น: เฮดลamp is IP68 rated, providing total protection from water, dirt, and dust. It continues to work even at 10 meters depth. After exposure to saltwater or harsh environments, rinse the headlamp with fresh water and dry thoroughly.

Image: The Armytek Wizard C2 Pro Max headlamp held in a hand, with water droplets visible, showcasing its waterproof capabilities.
การแก้ไขปัญหา
- ไฟไม่เปิด:
- ตรวจสอบให้แน่ใจว่าแบตเตอรี่ชาร์จเต็มและใส่เข้าไปอย่างถูกต้อง
- Check that the tailcap is fully tightened.
- ปัญหาการชาร์จ:
- If the light is not charging, ensure you unscrew the tailcap to 1/4 turn before connecting the magnetic charging cable.
- ตรวจสอบว่าสาย USB และแหล่งพลังงานทำงานอย่างถูกต้อง
- Overheating/Step-down: The light features active real-time temperature control to prevent overheating above 58°C. This is a normal function to protect the electronics and ensure longevity. If the light steps down in brightness, it indicates it is managing its temperature.
ข้อมูลจำเพาะ
| คุณสมบัติ | ข้อมูลจำเพาะ |
|---|---|
| ยี่ห้อ | อาร์มี่เทค |
| แบบอย่าง | Wizard-C2-Pro-Max |
| ประเภท LED | Cree XHP70.2 |
| เลนส์ | ทีไออาร์ |
| เอาท์พุตแสง | 4000 ลูเมน (สูงสุด) |
| ระยะลำแสง | 114 เมตร |
| เสถียรภาพความสว่าง | Full (constant light) |
| จุดเสี่ยง: การรั่วไหล | 110 °: 150 ° |
| จำนวนโหมด | 6 simple / 10 advanced |
| Runtime (minimum mode) | 2 months (Firefly) |
| โหมดแฟลช | Yes (3 types) |
| เส้นผ่านศูนย์กลางหัว | 34.4 มม. |
| เส้นผ่านศูนย์กลางตัวเครื่อง | 23.6 มม. |
| ความยาว | 121.5 มม. |
| น้ำหนัก (ไม่รวมแบตเตอรี่) | 79 กรัม |
| กันน้ำ & กันฝุ่น | IP68 |
| ความลึกที่ปลอดภัยสำหรับการจุ่มน้ำ | 10 เมตร |
| ความสูงที่ปลอดภัยในการตก | 10 เมตร |
| อุณหภูมิในการทำงาน | -25°C ถึง +40°C |
| แหล่งพลังงาน | แบตเตอรี่ลิเธียมไอออน 1 ก้อน (รวมอยู่ด้วย) |
| วัสดุ | อลูมิเนียมเกรดอากาศยาน |
การรับประกัน
The Armytek Wizard C2 Pro Max comes with a รับประกัน 10 ปี, ensuring long-term reliability and support for your product.
สนับสนุน
For further assistance, technical support, or warranty claims, please refer to the official Armytek webเข้าชมเว็บไซต์หรือติดต่อฝ่ายบริการลูกค้าโดยตรง เก็บใบเสร็จรับเงินไว้เป็นหลักฐานการซื้อเพื่อใช้ในการรับประกัน
