HW HAOWORKS S278 เครื่องบันทึกเสียงพกพา Ampคู่มือการใช้งาน lifier

1. สินค้าหมดview

The HW HAOWORKS S278 is a versatile 15W portable voice amplifier designed to enhance vocal projection for various applications such as teaching, tour guiding, fitness instruction, and public speaking. It features multiple connectivity options including Bluetooth, AUX, TF card, and USB, along with FM radio and recording capabilities. Its lightweight and compact design ensures ease of portability and use.

Image: The HW HAOWORKS S278 Portable Voice Amplifier, a compact black device with a speaker grille and control panel, shown with its wired headset microphone.

2. การตั้งค่า

2.1 เนื้อหาบรรจุภัณฑ์

เมื่อแกะกล่อง ตรวจสอบว่ามีส่วนประกอบทั้งหมดครบถ้วน:

• 1 เท่า Amplifier ลำโพง
• 1 x Wired Headset Microphone
• 1 x Adjustable Belt
• สาย 1 x AUX
• สาย USB 1 เส้น
• 1 x คู่มือผู้ใช้

ภาพ: รายละเอียด view of the HW HAOWORKS S278 voice amplifier and its accessories, including the headset microphone, USB cable, AUX cable, adjustable belt, and user manual, with labels pointing to various ports and controls on the ampชีวิต.

2.2 การชาร์จ Ampชีวิต

Before initial use, fully charge the voice amplifier. The device typically takes 3-5 hours to achieve a full charge, providing up to 12 hours of continuous operation.

• เชื่อมต่อสาย USB ที่ให้มาเข้ากับพอร์ตชาร์จบน ampชีวิต.
• Plug the other end of the USB cable into a compatible USB power source (e.g., computer USB port, wall adapter).
• ไฟแสดงสถานะการชาร์จบนหน้าจอจะแสดงสถานะการชาร์จ

Image: An illustration highlighting the long battery life of the HW HAOWORKS S278 voice amplifier, showing a 2500 mAh battery, 3-5 hours charging time, and 10-12 hours working time, with people practicing yoga in the background.

2.3 Connecting the Wired Headset Microphone

เสียง amplifier comes with a high-performance wired headset microphone for clear voice input.

• Locate the 3.5mm Mic-in jack on the ampชีวิต.
• Insert the 3.5mm plug of the headset microphone firmly into the Mic-in jack.
• Adjust the headset for a comfortable fit, ensuring the microphone is positioned 2-3 cm from your mouth for optimal sound capture. The headset features a 270-degree rotatable fulcrum for easy adjustment.

Image: A close-up of the wired headset microphone, detailing its highly sensitive recording mic, non-slip surface, 270-degree rotatable fulcrum, and double-shielded wire cable. Insets show how to wear the headset and position the microphone.

3. คู่มือการใช้งาน

3.1 การเปิด/ปิดเครื่องและการควบคุมระดับเสียง

To power on the device, slide the ON/OFF switch located on the top of the amplifier. The digital display screen will illuminate. The same switch also functions as the volume control; slide it to increase or decrease the ampระดับการทำให้เป็นกรด

Image: The HW HAOWORKS S278 voice amplifier shown in a classroom setting with children, highlighting its easy volume control switch and durable, wear-resistant design.

การเลือกโหมด 3.2

การ amplifier supports various modes for different functionalities. Press the 'M' (Mode) button on the control panel to cycle through the available modes:

• โหมดบลูทู ธ : Allows wireless connection to your smartphone or other Bluetooth-enabled devices for audio streaming. The display will show "BLUE" when in Bluetooth mode.
• โหมดวิทยุ FM: Enables listening to FM radio stations. To change stations, hold down the arrow buttons.
• อินพุต AUX: Connect external audio devices via the 3.5mm AUX cable.
• TF Card Playing: Insert a TF (Micro SD) card to play audio fileโดยตรงเลย
• กำลังเล่น USB Flash Drive: Insert a USB flash drive to play audio fileโดยตรงเลย

Image: A visual representation of the HW HAOWORKS S278's multifunctional design, illustrating its capabilities as a Bluetooth speaker, AUX input, TF card player, U disk (USB) player, FM radio, and one-key voice recorder.

3.3 เสียง Ampการทำให้บริสุทธิ์

เอส278 amplifier provides clear and loud voice projection, suitable for rooms of 25 to 60 people or outdoor spaces for 25 to 65 people, covering up to 10,000 square feet. This helps protect your vocal cords by reducing the need to yell.

Image: A graphic illustrating the high-power and Hi-Fi sound projection of the HW HAOWORKS S278 voice amplifier, indicating its suitability for indoor (25-100 people) and outdoor (25-65 people) use, covering 10,000 sq ft, with a clear sound projection.

3.4 ฟังก์ชั่นการบันทึก

การ amplifier supports one-key recording. To use this feature, ensure a TF/SD card is inserted into the designated slot and the wired microphone is connected. Press the 'Record' button to begin recording. Recorded audio can be played back through the ampชีวิต.

3.5 การสวมใส่ Ampชีวิต

The S278 is designed for portability. It can be easily worn using the included adjustable belt, either around your waist or hung around your neck, allowing for hands-free operation while moving.

Image: Three individuals demonstrating different ways to wear the lightweight and small HW HAOWORKS S278 voice amplifier: around the waist, over the shoulder, and clipped to clothing, emphasizing its portability.

4. การบำรุงรักษา

To ensure the longevity and optimal performance of your voice ampเครื่องขยายสัญญาณ ให้ปฏิบัติตามคำแนะนำการบำรุงรักษาดังต่อไปนี้:

• การทำความสะอาด: ใช้ผ้าแห้งเนื้อนุ่มทำความสะอาดด้านนอกของตัวเครื่อง amplifier. Avoid using harsh chemicals or abrasive materials that could damage the surface.
• พื้นที่จัดเก็บ: จัดเก็บ amplifier in a cool, dry place away from direct sunlight and extreme temperatures. When not in use for extended periods, ensure it is fully charged before storage.
• การดูแลแบตเตอรี่ Do not expose the battery to high temperatures or attempt to disassemble it. Charge the device regularly, even if not in frequent use, to maintain battery health.

5 การแก้ไขปัญหา

If you encounter issues with your voice ampเครื่องขยายสัญญาณ อ้างอิงถึงปัญหาทั่วไปและวิธีแก้ไขต่อไปนี้:

• ไม่มีเสียง/ระดับเสียงต่ำ:
  • ให้แน่ใจว่า amplifier is powered on and fully charged.
  • Check the volume level and increase it as needed.
  • Verify that the headset microphone is securely plugged into the Mic-in jack.
• Howling/Feedback:
  • Position the headset microphone and the speaker a sufficient distance from each other.
  • Ensure the microphone is not directly facing the speaker.
  • Reduce the volume setting if it is too high.
  • Adjust the microphone's position relative to your mouth (ideally 2-3 cm away).
• ปัญหาการเชื่อมต่อบลูทูธ:
  • ให้แน่ใจว่า amplifier is in Bluetooth mode.
  • Check that Bluetooth is enabled on your external device.
  • ย้าย amplifier closer to your device to ensure it is within range.
• ปัญหาในการบันทึก:
  • Confirm that a TF/SD card is properly inserted.
  • Ensure the wired microphone is connected.
  • Check for sufficient storage space on the TF/SD card.

For persistent issues not covered here, please consult the original user manual provided with your product or contact HW HAOWORKS customer support.

6. ข้อมูลจำเพาะ

7. การรับประกันและการสนับสนุน

For warranty information and customer support, please refer to the documentation included with your purchase or visit the official HW HAOWORKS website. Typically, warranty details and contact information for support are provided by the manufacturer.
