Eveready General Purpose LED Flashlight User Manual

รุ่น : 30039800120831

1. บทนำ

Thank you for choosing the Eveready General Purpose LED Flashlight. This manual provides important information on the safe and effective use of your new flashlight. Designed for basic lighting needs, this flashlight features bright, energy-efficient LED technology that is up to 5 times brighter than ordinary LED technology, offering a strong beam and extended runtime. Its ribbed design ensures a secure grip, and the convenient push-button switch allows for easy operation.

Two Eveready flashlights, one red and one blue, with two D-cell batteries.
Figure 1: Eveready General Purpose LED Flashlight 2-Pack with D-cell batteries.

This image displays the Eveready General Purpose LED Flashlight 2-Pack, featuring one red and one blue flashlight, alongside two Eveready D-cell batteries. The packaging highlights 'LED Technology' and '60h of runtime'.

2. ข้อมูลด้านความปลอดภัย

Please read all instructions and cautionary markings on the package and the flashlight before use. Failure to follow these instructions may result in fire, explosion, or leakage.

  • อย่าผสมแบตเตอรี่เก่ากับใหม่
  • ห้ามผสมแบตเตอรี่อัลคาไลน์ แบตเตอรี่มาตรฐาน (คาร์บอน-สังกะสี) หรือแบตเตอรี่ชาร์จไฟได้ (นิกเกิล-แคดเมียม)
  • อย่าทิ้งแบตเตอรี่ด้วยการเผาไฟ แบตเตอรี่อาจระเบิดหรือรั่ว
  • Remove batteries from the product before extended storage to prevent leakage.
  • Do not look directly into the LED light source, as this may cause eye damage.
Back of Eveready flashlight packaging with warnings and product information.
Figure 2: Back of Product Packaging with Safety Warnings.

This image shows the reverse side of the Eveready flashlight packaging, detailing important safety warnings regarding battery usage and disposal, along with manufacturing and contact information.

3. เนื้อหาบรรจุภัณฑ์

Your Eveready General Purpose LED Flashlight package includes:

  • 2 x Eveready General Purpose LED Flashlights (one red, one blue)
  • 2 x Eveready D Batteries

4. การตั้งค่า: การติดตั้งแบตเตอรี่

การติดตั้งหรือเปลี่ยนแบตเตอรี่:

  1. คลายเกลียวหัวไฟฉายทวนเข็มนาฬิกาเพื่อเปิดช่องใส่แบตเตอรี่
  2. Insert one D-cell battery into the flashlight with the positive (+) end facing towards the head of the flashlight.
  3. Screw the head back onto the flashlight clockwise until it is securely tightened.
Red Eveready flashlight with two D-cell batteries.
Figure 3: Flashlight with D-cell Batteries.

This image shows a red Eveready flashlight alongside two D-cell batteries, illustrating the type of battery required for operation.

5. คู่มือการใช้งาน

The Eveready General Purpose LED Flashlight is designed for simple and straightforward use.

  • การเปิด/ปิด: Locate the push-button switch on the side of the flashlight. Press the button once to turn the flashlight ON. Press the button again to turn the flashlight OFF.
  • การยึดเกาะที่มั่นคง: The flashlight features a ribbed design along its body, providing a secure and comfortable grip during use.
  • การให้แสงสว่างที่สดใส: The advanced LED technology delivers a bright, long-lasting beam suitable for various general purpose lighting tasks.
Close-up of a bright, long-lasting LED flashlight beam.
Figure 4: Bright, Long-Lasting LED.

This close-up image highlights the bright, long-lasting LED light emitted by the Eveready flashlight, emphasizing its 25 lumens output.

Eveready flashlight being used in various household scenarios.
Figure 5: Flashlight in Use.

This composite image demonstrates the Eveready flashlight's utility in different settings, including illuminating a fuse box and providing light for plumbing work under a sink.

Man and child using an Eveready flashlight to change a tire at night.
Figure 6: Practical Application.

This image shows a man and a child using an Eveready flashlight to illuminate a car tire at night, demonstrating its practical use in low-light conditions.

6. การบำรุงรักษา

  • การทำความสะอาด: Wipe the exterior of the flashlight with a soft, dry cloth. Do not use abrasive cleaners or immerse the flashlight in water.
  • การเปลี่ยนแบตเตอรี่: Replace batteries when the light dims significantly or stops working. Always use fresh D-cell batteries. Refer to Section 4 for battery installation instructions.
  • พื้นที่จัดเก็บ: For extended storage, remove the batteries from the flashlight to prevent potential leakage and damage to the device. Store in a cool, dry place.

7 การแก้ไขปัญหา

ปัญหาสาเหตุที่เป็นไปได้สารละลาย
ไฟฉายไม่ติดแบตเตอรี่หมดหรือใส่ไม่ถูกต้องCheck battery orientation. Replace with fresh D-cell batteries.
แสงสว่างสลัวๆพลังงานแบตเตอรี่ต่ำReplace with fresh D-cell batteries.
ไฟกะพริบLoose battery connection or low battery.Ensure battery compartment is tightly closed. Replace batteries if needed.

8. ข้อมูลจำเพาะ

คุณสมบัติรายละเอียด
หมายเลขรุ่น30039800120831
แหล่งพลังงานใช้พลังงานจากแบตเตอรี่
ประเภทแหล่งกำเนิดแสงนำ
ความสว่างสีขาว9 Lumens (up to 25 lumens as per packaging)
รันไทม์40 hours (up to 60 hours as per packaging)
ประเภทแบตเตอรี่2 x D batteries (Zinc Carbon / Alkaline)
วัสดุพลาสติก
สีMulticolor (Red, Blue)
ขนาดสินค้าลึก 2.6 นิ้ว x กว้าง 7.25 นิ้ว x สูง 9.5 นิ้ว
น้ำหนักสินค้า11.7 ออนซ์
ระดับความต้านทานต่อน้ำไม่ทนน้ำ
ผู้ผลิตEnergizer Battery Company, inc.

9. การรับประกันและการสนับสนุน

This Eveready flashlight comes with a Limited Warranty. For specific details regarding warranty coverage, terms, and conditions, please refer to the product packaging or contact Energizer Battery Company, Inc. directly.

For customer support or inquiries, please visit the official Eveready webหรือติดต่อฝ่ายบริการลูกค้า ข้อมูลการติดต่อมักจะอยู่บนบรรจุภัณฑ์ของผลิตภัณฑ์หรือเว็บไซต์อย่างเป็นทางการของพวกเขา webเว็บไซต์.

ผู้ผลิต: Energizer Battery Company, inc.

ยูพีซี: 039800120830
