คู่มือผู้ใช้ Metra Axxess ASWC-1 ระบบควบคุมพวงมาลัย

1. บทนำ

The Axxess ASWC-1 is a universal steering wheel control interface designed to retain the factory steering wheel audio controls when installing an aftermarket radio. This interface is compatible with all major radio brands and features automatic vehicle and radio detection for simplified installation. It also supports manual programming and the ability to dual assign steering wheel control buttons.

This manual provides essential information for the proper setup, operation, and maintenance of your ASWC-1 interface.

2. สินค้าหมดview

Figure 2.1: The Axxess ASWC-1 interface module with its accompanying wiring harnesses and connectors, including a Micro B USB connector for updates.

Figure 2.2: The ASWC-1 interface as packaged, showing the module and wiring visible through the clear plastic.

Figure 2.3: The reverse side of the ASWC-1 packaging, highlighting key features such as compatibility with most aftermarket radios, auto-detection, and USB updatability.

Figure 2.4: A dedicated QR code for accessing the ASWC-1 application guide, which provides detailed compatibility information.

คุณสมบัติหลัก:

• Micro “B” USB updatable for future compatibility and firmware enhancements.
• One interface does it all – no additional interfaces needed for basic functionality.
• Designed to be compatible with all major radio brands.
• Automatically detects vehicle type, radio connection, and presets controls for ease of installation.
• Ability to dual assign steering wheel control buttons, allowing for more functions from fewer buttons.
• Can be manually programmed for most vehicles.
• Provides Speed Dependent Volume Control on select CAN data vehicles.

3. การตั้งค่าและการติดตั้ง

Proper installation is crucial for the optimal performance of your ASWC-1 interface. It is recommended to consult the detailed installation manual specific to your vehicle and aftermarket radio. Ensure all connections are secure and insulated to prevent short circuits.

หมายเหตุการติดตั้งทั่วไป:

• Identify the correct wiring for your vehicle's steering wheel controls and your aftermarket radio's SWC input.
• Connect the ASWC-1 module according to the wiring diagram provided in the full installation manual.
• Ensure a good metal-to-metal contact for all wire connections. Loose connections can lead to malfunction.
• Secure all wiring with zip ties to keep them tidy and prevent interference.

Installation Resources:

For detailed, vehicle-specific installation instructions, please refer to the official documentation available for download:

• คู่มือการติดตั้ง (PDF)
• คู่มือผู้ใช้ (PDF)
• คำแนะนำการใช้งาน (IFU) (PDF)
• คู่มือการใช้งาน (PDF)
• คู่มือการติดตั้งสำหรับยานพาหนะ
• ASWC-1 Application Chart

4. คู่มือการใช้งาน

The ASWC-1 interface is designed for automatic detection and programming. However, manual programming, resetting, and remapping functions are available for specific scenarios or advanced customization.

4.1. Manual Programming

If automatic detection fails or you wish to customize button functions, the ASWC-1 can be manually programmed. This involves a sequence of pressing the reset button on the module and specific steering wheel control buttons.

4.2. Resetting the ASWC-1

A reset may be necessary if the module is not functioning as expected or if you are installing it in a new vehicle/radio setup. Resetting clears all previous programming.

4.3. Changing the Radio Type

The ASWC-1 automatically detects the radio type. However, if you change your aftermarket radio or if the automatic detection is incorrect, you can manually set the radio type.

4.4. Remapping Steering Wheel Controls

Remapping allows you to assign different functions to your steering wheel buttons than their default or automatically detected settings. This is useful for custom configurations.

5. การบำรุงรักษา

The ASWC-1 is designed to be a low-maintenance device. The primary maintenance activity is keeping its firmware updated to ensure compatibility with new vehicles and aftermarket radios, and to benefit from any performance improvements.

อัพเดตเฟิร์มแวร์:

The ASWC-1 features a Micro “B” USB port for firmware updates. Visit the Axxess Interfaces website for the latest firmware and instructions on how to update your module. Regular updates can prevent compatibility issues and enhance functionality.

6 การแก้ไขปัญหา

If you encounter issues with your ASWC-1 interface, please refer to the official troubleshooting guide. Common issues often relate to incorrect wiring, improper programming sequences, or outdated firmware.

Common Troubleshooting Tips:

• No Functionality: Double-check all wiring connections against the vehicle-specific installation manual. Ensure proper power and ground connections.
• Incorrect Button Response: Perform a full reset of the ASWC-1 module and re-attempt the programming sequence (either automatic or manual). Verify the correct radio type is selected.
• ข้อเสนอแนะ LED: Familiarize yourself with the LED feedback patterns (green, red, flashing sequences) as they indicate the module's status and can help diagnose issues. Refer to the "AXXESS ASWC-1 LED Feedback" video in Section 4.2.
• การทำงานเป็นระยะ: Check for loose connections or interference from other electrical components.

For more detailed troubleshooting steps, download the official guide:

• คู่มือการแก้ไขปัญหา (PDF)

7. ข้อมูลจำเพาะ

8. ข้อมูลการรับประกัน

The Metra Axxess ASWC-1 comes with a manufacturer's warranty, as the product is brand new. For specific details regarding warranty coverage, duration, and claims procedures, please refer to the documentation included with your product or contact Axxess customer support.

9. การสนับสนุนและแหล่งข้อมูล

For further assistance, technical support, or additional resources, please use the following contact information and links:

• โทรศัพท์ฝ่ายสนับสนุนด้านเทคนิค: 386-257-1187
• เป็นทางการ Webเว็บไซต์: axxessinterfaces.com
• ข้อมูลด้านความปลอดภัย: ข้อมูลด้านความปลอดภัย (PDF)
• Fact Sheet: เอกสารข้อมูล (ผู้ให้บริการ) (PDF)

Always ensure you are using the latest documentation and firmware for the best experience with your ASWC-1 interface.
