Starting the Motor Grader
Once the motor grader has started, allow the accelerator pedal to reach its extreme position. To achieve the desired working speed, pull back on the governor control lever or press down on the accelerator lever pad.
รูปที่ 6: This image illustrates the operator's hand engaging with the accelerator lever pad, which is used to adjust the motor grader's working speed.
หมายเหตุการดำเนินงานที่สำคัญ
- Tandem Tires: Avoid spinning tandem tires. Spinning tires can cause a digging action, damage road surfaces, and lead to excessive tire wear.
- การเปลี่ยนเกียร์: To prevent gears from clashing when shifting to a higher gear, depress the clutch pedal. Allow 3 to 4 seconds to elapse before engaging the shift levers.
Engine Shut-Down Procedures
Cummins Engine
- Ensure gear shift levers are in the neutral position.
- Press down on the button located in the center of the governor control lever knob.
- Push the lever forward to the idling position.
- Allow the engine to run for a few minutes.
- Turn the key in the ignition switch counter-clockwise to the shut-down position. This action de-activates the solenoid shut-down valve on the fuel pump.
บันทึก: For additional information regarding the solenoid shut-down valve, refer to the Engine Manufacturer's Operators and Maintenance Manual.
General Motors Engine
- Ensure gear shift levers are in the neutral position.
- Press down on the button located in the center of the governor control lever knob.
- Push the lever to the idling position.
- Allow the engine to run for a few minutes.
- Raise the sliding sleeve on the lever.
- Push the lever forward until the engine shuts down.
แผงหน้าปัดโอเวอร์view
Figure 7 provides a view of the instrument panel, located on the left side of the power box.
รูปที่ 7: This image displays the instrument panel, showing various gauges essential for monitoring the grader's operation.
Gauge Descriptions
- เกจวัดระดับน้ำมัน: The oil pressure gauge must indicate pressure while the engine is running. Consult the Engine Manufacturer's Operators and Maintenance Manuals for specific correct pressure readings.
- แอมมิเตอร์: การ amperes gauge should not show discharge or fluctuate when the engine is operating at normal speeds. If the gauge indicates fluctuation or discharge, contact your LeTourneau-Westinghouse Distributor for service.
- มาตรวัดอุณหภูมิ: The temperature gauge displays the water temperature in the engine. Refer to the Engine Manufacturer's Operators and Maintenance Manual for correct readings.
ข้อมูลทั่วไป
การตั้งค่า
Initial setup procedures for the Adams 440 Grader are detailed in the full operator's manual. Ensure all pre-operation checks are completed before starting the machine.
การซ่อมบำรุง
Regular maintenance is crucial for the longevity and optimal performance of your Adams 440 Grader. Refer to the comprehensive Engine Manufacturer's Operators and Maintenance Manual for detailed service schedules and procedures.
การแก้ไขปัญหา
For common operational issues and their resolutions, consult the troubleshooting section of the complete Adams 440 Grader manual. For complex problems, contact authorized service personnel.
ข้อมูลจำเพาะ
Detailed technical specifications for the Adams 440 Grader, including engine type, dimensions, and operational capacities, are available in the full product manual.
การรับประกันและการสนับสนุน
Information regarding product warranty and customer support contacts can be found in the documentation provided with your Adams 440 Grader. Please retain your purchase receipt for warranty claims.
